Telephone Cables

 Cellular PE Insulated & PE Sheathed Jelly Filled Cables to CW1236


Application

The cables are fully filled with petroleum jelly, being designed for use in access or trunk networks, from telephone exchange to subscriber area. The cables are suitable for installation in ducts and direct burial in the ground.

Standards

• CW1236









Construction

Conductors
Solid annealed bare copper 0.32/0.4/0.5/0.63/0.9mm as per class 1 of BS 6360/IEC 60228

Insulation
Cellular polyethylene as per BS 6234/BS EN 50290-2-23/IEC 60708

Twisted Pairs
Insulated conductors are twisted into pairs with varying lay length to minimize crosstalk

Cabling Element
Twisted Pairs

Cable Core Assembly
Cables with up to 100 pairs are composed of 25-pair units or 12/13-pair units; cables with over 100 pairs are composed of 25, 50 or 100-pair units cabled together. Any extra pairs form a separate unit. Units are identified by colour coded binders. Standard construction is per CW 1236 given in Cable Make Up Diagram

Core Wrapping
One or more non-hygroscopic polyester tapes are helically or longitudinally laid with an overlap. These tapes furnish thermal, mechanical as well as high dielectric protection between shielding and individual conductors

Moisture Barrier(optional)
An optional aluminium tape (0.15mm) coated with PE-copolymer on one or both sides is applied longitudinally with overlap over the cable core to provide 100% electrical shielding coverage and ensures a barrier against water vapor

Filling
The cable core interstices are filled with petroleum jelly to avoid longitudinal water penetration within the cable. The water resistant filling compound is applied to the air space between non-hygroscopic tape and shield, shield and sheath within the cable core

Sheath
Black low density polyethylene as per BS 6234/IEC 60708, being able to withstand exposure to sunlight, temperature variations, ground chemicals and other environmental contaminants

Ripcord
Ripcord may be provided for slitting the sheath longitudinally to facilitate its removal

Spare Pairs (optional)
Spare pairs may be incorporated for 200 and larger pair cables

Continuity Wire (optional)
One tinned copper drain wire may be longitudinally laid to ensure electrical continuity of the screen

Optional Construction

Armoured Cable
Steel wire armour or corrugated steel tape armour is applied over an optional inner polyethylene sheath. For steel tape version, the 0.15mm thick steel tape is coated with a copolymer and applied with an overlap. An outer polyethylene sheath is applied over the armour

Electrical Properties

Nominal Conductor Diameter

mm

0.32

0.4

0.5

0.63

0.9

Conductor Gauge Size

AWG

28

26

24

22

19

Conductor Size

mm2

0.08

0.126

0.196

0.312

0.636

Maximum Average Conductor Resistance @20°C

Ω/km

223

143

91

58

28

Minimum Insulation Resistance @500V DC

MΩ.km

1500

1500

1500

1500

1500

Maximum Average Mutual Capacitance @800Hz*

nF/km

56

56

56

56

59

Maximum Individual Mutual Capacitance @800Hz (for 99% cases)

nF/km

64

64

64

64

65

Maximum Individual Capacitance Unbalance @800Hz pair-to-pair
(for 99% cases)

pF/500m

275

275

275

275

275

Maximum Conductor Loop Resistance @20°C

Ω/km

470

300

192

114

60

Impedance @1KHz

1000

994

796

660

445

Impedance @100KHz

156

147

134

125

122

Impedance @512KHz

122

120

118

117

116

Impedance @1MHz

120

117

115

114

113

Maximum Average Attenuation @0.8KHz

dB/km

1.76

1.64

1.30

1.04

0.74

Maximum Average Attenuation @1KHz

dB/km

1.8

1.68

1.35

1.08

0.76

Maximum Average Attenuation @3KHz

dB/km

3.4

3.18

2.52

2.01

1.42

Maximum Average Attenuation @150KHz

dB/km

16.8

11.4

8.3

6.2

4.4

Maximum Average Attenuation @772KHz

dB/km

29.5

24.3

19.4

15.4

10.8

Maximum Average Attenuation @1000KHz

dB/km

33.5

27.1

21.4

17.5

12.8

Dielectric Strength Conductor to Conductor (3secs)

V DC

500

500

500

500

500

Nominal Insulation Thickness

mm

0.145

0.175

0.20

0.26

0.30

Nominal Insulated Conductor Diameter

mm

0.61

0.75

0.90

1.15

1.50





























*Mutual capacitance values for 0.63mm & 0.9mm may be increased by 3% for cables with a nominal number of pairs less than 400.

Mechanical and Thermal Properties

Temperature range during operation (fixed state): -30°C – +70°C
Temperature range during installation (mobile state): -20°C – +50°C
Minimum bending radius: 10 x Overall Diameter (unarmoured cables);15 x Overall Diameter (armoured cables)

Colour Code
Standard colour code is per CW 1236 given in Colour Code Chart
